Replacing Bulb(s) For Left or Right Rear Light (on Bumper Trim)

63 99 312 - Replacing bulb(s) for left or right rear light (on bumper trim) (up to 09/07)





Warning!
Follow instructions for handling light bulbs (exterior lights) Instructions for Handling Light Bulbs (Exterior Lights).





Necessary preliminary tasks:
- Remove bumper trim





Turn socket housing for rear light (1) or (2) and remove from rear light (3).
1. Socket housing of bulb for rear fog light
2. Socket housing of bulb for reversing light





Turn bulb for rear light (1) in direction of arrow and remove from rear light socket housing (2).

Installation Note:
Note type of bulb Rear Light Cluster (up to 09/07).
