Home >> BMW >> 2007 >> M6 Convertible (E64) V10-5.0L (S85) >> Repair and Diagnosis >> Diagrams >> Electrical Diagrams >> Drive >> SMG Transmission Control (SMG Sequential Manual Transmission) >> Selector Lever

Selector Lever

Selector lever and gear indicator lighting Part 1:



Selector lever and gear indicator lighting Part 2:



Selector lever and gear indicator lighting Part 3:
