Home >> BMW >> 2007 >> 525xi Sedan AWD (E60) L6-3.0L (N52) >> Repair and Diagnosis >> Diagrams >> Electrical Diagrams >> Body >> Seats (5 Series_E60/E61) >> Seat Adjustment, Passenger's Side >> Passenger's Seat Adjustment (As of 09/05 Up to 03/07 W/ SMBF Seat Module, Passenger W/ (Lumbar Support, Sport or Active Seat))

Passenger's Seat Adjustment (As of 09/05 Up to 03/07 W/ SMBF Seat Module, Passenger W/ (Lumbar Support, Sport or Active Seat))
