Replacing Shift Arm For Shift-Lever Mount

25 11 211 Replacing shift arm for shift-lever mount

Necessary preliminary tasks:
^ Remove shift lever.
^ Support transmission with hydraulic lifter.





Release screws and remove cross-member (1).
Tightening torque:
M12 74 Nm.
M10 41 Nm.
M8 21 Nm.





Release screws on propeller shaft center mount (1).
Lower transmission.





Use a screwdriver to lift out spring (1) from the lug (2) on the housing and swivel upwards.





Remove bearing pin (1).

Installation:
Grease bearing pins (1).
Grease,
refer to BMW Service Operating Fluids.

Note: Do not remove support bearing (1).
Do not remove shift arm (2) from support bearing (1).

Installation:
Grease bearing pin of shift arm.
Grease,
refer to BMW Service Operating Fluids.





Note: If bearing bush is damaged: replace bearing bush.

Press out bearing bush.
Coat new bearing bush with circo light and then press into shift arm until side flanges of bearing bush protrude uniformly.
circo light,
refer to BMW Parts Service.
