Home >> BMW >> 2006 >> X5 (E53) L6-3.0L (M54) >> Repair and Diagnosis >> Diagrams >> Electrical Diagrams >> Body >> Audio, Video and Navigation >> Radio >> External Audio Connection (As of 09/02)

External Audio Connection (As of 09/02)

E53 Connection, AUX socket Part 1 Of 1:
