Clutch Release Bearing: Service and Repair

Replacing guide tube for clutch release mechanism (S6S 420G)
(transmission removed)

Remove clutch release bearing and release lever from guide tube.





Unfasten screws. Remove guide tube (1).

Installation:
Clean thread.
Install screws with Loctite 243.
Tightening Torque, refer to Technical Data 23 11 2AZ.






Note: Remove sticker (1) and adhesive with a suitable solvent.
