Home >> BMW >> 2006 >> M3 Convertible (E46) L6-3.2L (S54) >> Repair and Diagnosis >> Diagrams >> Electrical Diagrams >> Chassis >> Wheel Slip Control System >> DSC MK60 (DSC Dynamic Stability Control MK60 (W/O ASC MK60 or W/O ASC MK60 W/ RPA)) >> Brake Light Switch >> Brake Light Switch (SMG Sequential Manual Transmission)

Brake Light Switch (SMG Sequential Manual Transmission)

Brake-light Switch:
