Home >> BMW >> 2006 >> M3 Convertible (E46) L6-3.2L (S54) >> Repair and Diagnosis >> Diagrams >> Electrical Diagrams >> Body >> Seat, Steering-Column, Mirror Functions >> Seat Adjustment, Passenger's Side >> Entrance Aid (SMB Entrance Aid, Passenger)

Entrance Aid (SMB Entrance Aid, Passenger)

Backrest switch, entry facility, front passenger's side:
