Home >> BMW >> 2006 >> M3 Convertible (E46) L6-3.2L (S54) >> Repair and Diagnosis >> Diagrams >> Electrical Diagrams >> Body >> Locking and Security Functions >> Convertible Top Control (CVM Convertible Top Module) >> Convertible-Top Actuation

Convertible-Top Actuation

Activation, electric convertible top:
