Home >> BMW >> 2006 >> M3 Convertible (E46) L6-3.2L (S54) >> Repair and Diagnosis >> Diagrams >> Electrical Diagrams >> Body >> Displays and Information >> Pointer Instruments (E.G. Speedometer, Fuel Gauge...) >> Oil Temperature Gauge (DME Motor Electronics MSS54) >> Coolant Temperature (Outlet)

Coolant Temperature (Outlet)

Coolant Temperature/electric Fan:
