Home >> BMW >> 2006 >> 750Li (E66) V8-4.8L (N62TU) >> Repair and Diagnosis >> Diagrams >> Electrical Diagrams >> Body >> Seats >> Lumbar Support, Passenger Side (SMBF Seat Module, Passenger) >> Passenger's Lumbar Support (Up To 03/06)

Passenger's Lumbar Support (Up To 03/06)

Passenger's lumbar support:
