Home >> BMW >> 2005 >> M3 Convertible (E46) L6-3.2L (S54) >> Repair and Diagnosis >> Diagrams >> Electrical Diagrams >> Chassis >> Wheel Slip Control System >> DSC MK20 (DSC MK20 Dynamic Stability Control W/O All-Wheel Drive) >> Transverse Acceleration Sensor

Transverse Acceleration Sensor

Lateral Acceleration Sensor:
