Home >> BMW >> 2005 >> M3 Convertible (E46) L6-3.2L (S54) >> Repair and Diagnosis >> Diagrams >> Electrical Diagrams >> Chassis >> Wheel Slip Control System >> DSC 5.7 (DSC Dynamic Stability Control (All-Wheel Drive) >> Switches, Sensors >> Lateral-Acceleration Sensor, Line

Lateral-Acceleration Sensor, Line

Rate Of Rotation Sensor:
