Home >> BMW >> 2005 >> M3 Convertible (E46) L6-3.2L (S54) >> Repair and Diagnosis >> Diagrams >> Electrical Diagrams >> Body >> Seat, Steering-Column, Mirror Functions >> Seat Adjustment, Passenger's Side >> Head-Restraint Adjustment (Convertible)

Head-Restraint Adjustment (Convertible)

Seat adjustment, passenger Part 1:



Seat adjustment, passenger Part 2:
