Home >> BMW >> 2005 >> M3 Convertible (E46) L6-3.2L (S54) >> Repair and Diagnosis >> Diagrams >> Electrical Diagrams >> Body >> Restraint and Rollover Protection Functions >> Rollover Sensor (Convertible URS Rollover Sensor)

Rollover Sensor (Convertible URS Rollover Sensor)

Rollover protection:
