Home >> BMW >> 2005 >> M3 Convertible (E46) L6-3.2L (S54) >> Repair and Diagnosis >> Diagrams >> Electrical Diagrams >> Body >> Restraint and Rollover Protection Functions >> Multiple Restraint System (MRS Multiple Restraint System III/IV) >> Seat-Backrest Locking (Convertible)

Seat-Backrest Locking (Convertible)

Switch, backrest lock Part 1:



Switch, backrest lock Part 2:
