Home >> BMW >> 2005 >> M3 Convertible (E46) L6-3.2L (S54) >> Repair and Diagnosis >> Diagrams >> Electrical Diagrams >> Body >> Locking and Security Functions >> Convertible Top Control (CVM Convertible Top Module) >> Valve Timing >> V5 Emergency Release

V5 Emergency Release

Drive, electric convertible soft top:
