Home >> BMW >> 2005 >> M3 Convertible (E46) L6-3.2L (S54) >> Repair and Diagnosis >> Diagrams >> Electrical Diagrams >> Body >> Locking and Security Functions >> Convertible Top Control (CVM Convertible Top Module) >> Power, K-Bus >> Supply, Convertible Soft Top Control Module

Supply, Convertible Soft Top Control Module

Supply, convertible soft top control module:
