Home >> BMW >> 2005 >> M3 Convertible (E46) L6-3.2L (S54) >> Repair and Diagnosis >> Diagrams >> Electrical Diagrams >> Body >> Lighting >> Interior Lights >> Lamps >> Trunk Compartment Light >> Luggage Compartment Lights (Coupe or Convertible As of 03/03)

Luggage Compartment Lights (Coupe or Convertible As of 03/03)

Luggage-compartment lighting:
