M3 Convertible (E46) L6-3.2L (S54)
>>
Repair and Diagnosis
>>
Diagrams
>>
Electrical Diagrams
>>
Body
>>
Heating and A/C Functions (IHKA Integrated Automatic Heating/A/C or IHKR Integrated Heating/A/C Regulation or Heater Control)
>>
Light, Display and LEDs
>>
Display and LEDs (IHKA Integrated Automatic Heating/A/C)
Display and LEDs (IHKA Integrated Automatic Heating/A/C)
Power supply:
