M3 Convertible (E46) L6-3.2L (S54)
>>
Repair and Diagnosis
>>
Diagrams
>>
Electrical Diagrams
>>
Body
>>
Displays and Information
>>
Displays
>>
Transmission Program (Automatic Transmission)
>>
Connector, CAN Bus (With DSC Dynamic Stability Control MK60 W/O DME MSS54 W/O ME9 Up to 09/01)
Connector, CAN Bus (With DSC Dynamic Stability Control MK60 W/O DME MSS54 W/O ME9 Up to 09/01)
Connector, CAN bus:
