Connector, CAN-Bus (DME Motor Electronics MS42 or MS43 With ASC MK20 Auto Stability Control to 09/01)
Connector, CAN-Bus (DME Motor Electronics MS42 or MS43 With ASC MK20 Auto Stability Control to 09/01)
Connector, CAN bus:
