Home >> BMW >> 2005 >> M3 Convertible (E46) L6-3.2L (S54) >> Repair and Diagnosis >> Diagrams >> Electrical Diagrams >> Body >> Audio, Video and Navigation >> Navigation (NAV Navigation Computer MKII or NAV Navigation Computer) >> Voice Output >> Navigation Tone >> Interface Signals, Radio Navigation (NAR Navigation Radio)

Interface Signals, Radio Navigation (NAR Navigation Radio)

Interface signals, radio navigation:
