Car Communication Computer (CCC

Car Communication Computer (CCC)
Model: E63/64
Production: Start of Production MY 2004



Car Communication Computer
In principle, the structure of the car communication computer corresponds to that of a personal computer. In the same way as a personal computer, the car communication computer contains a processor as well as RAM modules and other peripheral components. Certain functions such as the voice input control system are integrated in the form of software in the car communication computer.
The car communication computer is the central control module for all applications. It is always coupled with the 8.8" split-screen central information display. The car communication computer also features the high variant of the controller with haptic feedback.
The car communication computer is based on a modular design, i.e. the main systems of the communication network are integrated in the form of modules in the car communication computer. It can be configured and expanded corresponding to requirements. At the time of market launch, the following modules/functions will be integrated in the car communication computer:
^ Radio double tuner
^ DVD navigation system, Professional (map presentation)
^ Voice control system
^ ASK functions
^ MOSTCAN Gateway functions





The following advantages are achieved by combining several control units in one module:
^ Increased functionality by combining several systems
^ Easy to expand/upgrade by means of software with corresponding interfaces
^ Fewer plug connections therefore fewer potential fault sources
^ Reduced package space for control units
