Intake Air Duct: Service and Repair

13 54 250 - Replacing air intake hose (between air-mass flow sensor and throttle valve assembly) (N62, N62TU)





Necessary preliminary tasks:
- Switch off ignition
- Remove acoustic cover





Loosen hose clamps (1).
Detach air-mass flow sensor (2) from throttle valve assembly.
Detach air intake hose (2) from air-mass flow sensor.

Installation:
Check sealing rings for damage, replace if necessary.
