11 13 010 Removing and Installing / Replacing Oil Sump Top Section

Removing And Installing/Replacing Oil Sump Top Section (N62)


Special Tools Required:
- 17 0 030













Release screw, remove tensioner (1) from A/C compressor drive belt. (E65 only)





Release screws.





Release screws and remove oil sump top section.

Installation:
Replace sealing ring on oil dipstick guide tube.
Free sealing faces of seal debris and clean.

1. Replace seal.
2. Install oil sump.
3. Insert all screws on transmission end.
4. Tighten down all screws on oil sump.

Tightening torque 11 13 2AZ
