Cigarette Lighter And Charging Sockets (X Series_X3-E83 Up to 03/04)

Cigarette lighter and charging sockets Part 1:



Cigarette lighter and charging sockets Part 2:



Cigarette lighter and charging sockets Part 3:



Cigarette lighter and charging sockets Part 4:
