Home >> BMW >> 2003 >> M3 Convertible (E46) L6-3.2L (S54) >> Repair and Diagnosis >> Diagrams >> Electrical Diagrams >> Drive >> Transmission Control >> Transmission Management SMG (SMG Sequential M Transmission) >> Control Module >> Sensor, Longitudinal Acceleration >> Longitudinal Acceleration Sensor (Up to 09/02)

Longitudinal Acceleration Sensor (Up to 09/02)

Longitudinal Acceleration Sensor:
