Replacing Servodrive of Defrosting Flaps (Automatic A/C)

Replacing Servodrive Of Defrosting Flaps (Automatic A/C)

Remove trim for pedal assembly







Unclip air duct for footwell on left (2) at mounts (1) and remove in direction of arrow.







Disconnect plug connection (1)







Unclip lock (1) and pull out servodrive (2) in direction of arrow







Installation:
If necessary, align shaft of defrosting flaps to position of servodrive
