Neutral Safety Switch: Service and Repair

Fig. 3 Neutral Safety Switch Installation:

1. Remove selector lever and base, then drive out pin and separate lower section from this assembly.
2. Remove central gate screw, then switch.
3. When installing switch, ensure bosses or pins of switch fit into appropriate gate holes, Fig. 3.
4. Reassemble selector group.
