Rear Parking Aid Sensors (G203)/(G204)/(G205)/(G206)

Rear Parking Aid Sensors (G203)/(G204)/(G205)/(G206)

Removing






- Remove the bolts - arrows - on the bottom side of the bumper cover.

- Reach from below, behind the bumper cover and press both retaining tabs to the side - arrows - while pressing the sensor - 2 - through from the outside to the inside.






- Disconnect the electrical connector - 1 - on the sensor.

Installing

Install in reverse order of removal, observing the following:

- Install the lower section of the bumper cover.
