Driver's Door Control Module -J386-







Control modules in interior and rear part ofvehicle

Driver's Door Control Module -J386-


Component Location:





In driver's door -Arrow-.
Pin Connectors:
=> [ Connectors on ] Front Passenger's Door Control Module -J387-
