Rear Door Window Motor: Service and Repair

Window Regulator Motor






1 Left Rear Window Regulator Motor (V26)

• The window regulator motor can be removed or installed with the motor or door window in any position.

• Removing

- Remove the door trim.

- Remove the screws - 6 - and remove the window regulator motor from the window regulator.

• Installing

• For the correct tightening specifications refer to => [ Window Regulator Motor and Window Regulator Assembly Overview ] Window Regulator Motor and Window Regulator Assembly Overview.

Installation is reverse of removal, but note the following:

• The tabs - arrow - on the threaded pin must lock inside the door inner panel.

- Push the window regulator motor onto the threaded pins and tighten the screws - 6 -.

• With the window regulator motor switches connected, switch the ignition on and run the door windows up to the stop.

• Continue holding the window regulator switch for approximately 2 seconds so the basic setting and one-touch up/down function are activated.

2 Threaded pins

3 Window regulator

4 Bolt

• Torque => [ (Item 9) Bolt ] Window Regulator Motor and Window Regulator Assembly Overview

5 Connector

- Disconnect the connector from the window regulator motor.
