Backrest Cover and Backrest Cushion, Separating and Assembling, Standard Seat/Sport Seat

Backrest Cover and Backrest Cushion, Separating and Assembling, Standard Seat/Sport Seat

Special tools, testers and auxiliary items required

• Upholstery clip pliers (V.A.G 1634)

Removing






- Remove backrest cover together with backrest cushion. Refer to => [ Backrest Cover with Backrest Cushion, Standard Seat/Sport Seat ] Backrest Cover With Backrest Cushion, Standard Seat/Sport Seat.

- Pull off backrest cover - 1 - from the backrest cushion - 2 - as far as possible and cut upholstery clips - 3 - using pliers.

Installation

Install in reverse order of removal. Note the following:

Information for installation: for example tightening specifications, replacing body parts, refer to => [ Backrest Cover and Backrest Cushion Assembly Overview, Standard Seat/Sport Seat ] Backrest Cover and Backrest Cushion Assembly Overview, Standard Seat/Sport Seat.
