Home
>>
Audi
>>
2007
>>
A4 Quattro Wagon (8ED) L4-2.0L Turbo (BWT)
>>
Repair and Diagnosis
>>
Specifications
>>
Capacity Specifications
>>
Differential Assembly
>>
System Specifications
>>
Rear Final Drive 01R (01AA,01EA,02XA,0A3A,01V,01VA,09LA Transmission)
>>
With Automatic Transmission 01V, FWD and AWD
With Automatic Transmission 01V, FWD and AWD
Code Letters, Transmission Ratios and Capacities
With Automatic Transmission 01V, FWD and AWD
