Forward and Backward Seat Adjustment Motor, Assembly Overview - 2

Forward And Backward Seat Adjustment Motor, Assembly Overview







1 - Connector
2 - Seat inclination adjustment motor
- Removing
- Remove seat.
- Attach fixture for seat repair VAS 6136 to engine and transmission holder VAS 6095.
- Attach front seat to fixture for seat repair VAS 6136.
- Remove control unit.
- Disconnect connector - 1 -.
- Remove bolts - 3 - (2x).
- Remove seat inclination adjustment motor - 2 -.
- Installing
- Installation is in reverse order of removal.
3 - Bolts (2x)
- Tightening torque 10 Nm
4 - Forward and backward seat adjustment motor
5 - Backrest adjustment motor
