Insulation, Center Console

Insulation, Center Console







1 - Insulation, center console mount
2 - Glove compartment
3 - Bolts (3x)
- Only for 5-speed manual transmissions
4 - Insulation, gearshift
- For manual transmission
5 - Interior monitor control module
6 - Insulation, tunnel
7 - Parking brake lever filler piece
- Only with interior monitor
8 - Filler piece
- Only with interior monitor
9 - Insulation, gearshift
- For automatic transmission
