Power Mirror Switch: Service and Repair

Mirror Adjustment Switch -E43-, Removing And Installing

CAUTION:
Before beginning repairs on the electrical system:
- Switch off all electrical consumers.
- Switch ignition off and remove ignition key.

Removing
- Remove window lifter switch.







- Slide mounting frame -1- out of door trim in direction of arrow.







- Remove screw -arrow-.







- Slide switch trim -2- off door trim in direction of -arrow A-.
- Pull grab handle -1- out of door trim in direction of -arrow B-.







- Carefully release clip -arrow- and pull mirror adjustment switch -1- upwards out of door trim.







- Separate mirror adjustment switch -1- from trim -2- (release fastener -A-).

Installing
Install in reverse order of removal of removal, noting the following:
- Press mirror adjustment switch into mirror adjustment trim until fasteners engage.
- Press switch into switch mount until fasteners engage.
