Latch System, "Lower Anchors and Tethers For Children", Removing and Installing - TT Coupe

LATCH System, "Lower Anchors And Tethers For Children", Removing And Installing - TT Coupe

NOTE: The LATCH system, "Lower Anchors and Tethers for Children", is not applicable to TT Roadster.

Rear top tethers







- Pry out cover - 4 - on bottom side (direction of arrow).
- Remove bolt - 3 -.
- Remove anchor - 2 -.

- To remove strap - 1 -, remove rear seat upholstery.
- Illustration shows backrest without upholstery from behind.

2 - Threaded socket for child seat anchor

Rear lower anchors

NOTE: Rear lower anchors are not applicable to TT Coupe.
