With Manufacturer's Scan Tool

Basic Setting

With engine stopped and ignition switched on, the following operation can be carried out with the "Function 04" basic setting:
- Adaptation of the Throttle Drive Control to the Engine Control Module (ECM), Display group 060. Throttle Valve Control Module -J338-, Adaptation
- Vehicles with automatic transmission: Adaptation of kick-down function of Throttle Position (TP) Sensor to Engine Control Module (ECM), Display group 063

With the engine running, the following operations can be performed with the basic setting function:
- Generation of readiness code Readiness Code
- Performance of Oxygen Sensor (O2S) and Oxygen Sensor control

Conditions for operations with engine running
- No DTCs stored in Diagnostic Trouble Code (DTC) memory
- Coolant temperature at least 80 degrees C.
- Electrical devices switched off (coolant fan must not run during the test).
- Air conditioning switched off.
- Vehicles with automatic transmission: Selector lever in position P or N.

Work sequence
- Connect VAS 5051 tester and select vehicle system "01 - Engine electronics". Ignition must be switched on for this.
or, depending on desired operation:
- Start engine.







Display on VAS 5051:
- In selection -1-, click on diagnostic function "04 - Basic Setting".







Display on VAS 5051:
1 - Enter display group
- Enter desired 3-digit display group number in button field -2- and press -Q- button to confirm input.

Example:

- Press buttons -0-, -0- and -1- to select "display group number 001" and press -Q- button to confirm input.







Display on VAS 5051:
1. Measured values not in basic setting
2. Measured values in basic setting
3. Display group X
A. Activating basic setting

NOTE: Basic setting is initiated after button - A - is pressed.







Display on VAS 5051:
1. Display field 1
2. Display field 2
3. Display field 3
4. Display field 4

- End function "04 - Basic setting" by pressing square button.
