Outside Rear View Mirror, Removing and Installing

Outside Rear View Mirror, Removing And Installing







1. Front door

2. Combi bolt
- 8 Nm

3. Outside rear view mirror
- Remove door trim before disassembling.
- Pull off door seal in area of threaded connection.
- Unscrew bolts -1- and -4- and lift off outside rear view mirror upward.

4. Combi bolt
- 8 Nm
