License Plate Lamp: Service and Repair

License Plate Light

CAUTION: Before beginning repairs on the electrical system:

- Obtain the anti-theft radio security code.
- Switch the ignition off.
- Disconnect the battery Ground (GND) strap.
- After reconnecting battery, re-code and check operation of anti-theft radio. Also check operation of clock and power windows according to Owner's Manual.

License plate light, removing and installing

Removing
The license plate lights are located below the bottom lip on the rear lid.







- Open rear lid and push one side -arrow- of license plate light -1- toward the left (e.g. with thumb) and remove light from below.
- Remove bulb (12 V, 5 W) from clip holder.

Installing
Install in reverse order of removal.
