A/T Housing Main Shaft Bearing Removal (A/T)

A/T Housing Mainshaft Bearing Removal

Special Tools Required

- Driver Handle, 15 x 135L 07749-0010000
- Seal Driver Attachment, 80 mm I.D. 07VAD-P8A010A

1. Remove the reverse idler gear assembly A/T Housing Reverse Idler Gear Removal/Installation (A/T).

2. To remove the mainshaft bearing, expand the snap ring using snap ring pliers, then push the bearing out using the 15 x 135L driver handle and the 80 mm I.D. seal driver attachment. Do not remove the snap ring unless it is necessary to clean the groove in the transmission housing.
