A/T Housing Main Shaft Bearing Removal (A/T)

A/T Housing Mainshaft Bearing Removal

Special Tools Required

- Driver Handle, 15 x 135L 07749-0010000
- Bearing Driver Attachment, 78 x 80 mm 07NAD-PX40100

1. Remove the reverse idler gear assembly A/T Housing Reverse Idler Gear Removal/Installation (A/T).

2. To remove the mainshaft bearing, expand the snap ring using snap ring pliers, then push the bearing out using the driver handle and the 78 x 80 mm attachment. Do not remove the snap ring unless it is necessary to clean the groove in the transmission housing.
